Exit releases
Pushplates
The most rugged exit switches we know how to build, led by our most popular, the round-button H120. The front plate's travel, not the switch, takes the force of each press. ST models use a full-frame microswitch; PNZ models add our pneumatic time delay to hold the door unlocked for 1–60 seconds, with no power needed.
All timer pushplates are listed UL508 / CSA C22.2 No. 14-10 with MET Labs (file E113051).
Which pushplate do I need?
Answer four questions and we'll point you to the right model and a starting part number.
Answer the questions
Your recommended pushplate will appear here.
Engraving options: PE PUSH TO EXIT · EX EXIT · PO PUSH TO OPEN · PU PUSH TO UNLOCK · OP OPEN · HA Accessibility symbol · HC Handicapped symbol · N No text · CE Custom (no charge). Availability varies by model. Custom engraving can combine text with the accessibility or handicapped symbol on certain models; consult the factory.
Compare models
| Model | Size | Mounting | Button | |
|---|---|---|---|---|
| Pushplate 120 / 140Most popular | 4.5″ H × 2.75″ W | Single-gang electrical box | Round, 1⅝″ (H120) or 2″ (H140) | Details |
| Pushplate 100 | 4.5″ H × 2.75″ W | Single-gang electrical box | Full-plate rectangle | Details |
| Pushplate 110 | 4.5″ H × 1.75″ W | Narrow aluminum door frame (mullion) | Full-plate rectangle | Details |
| Pushplate 130 / 150 | 4.5″ H × 1.75″ W | Narrow aluminum door frame (mullion) | Round, 1⅝″ (H130) or 2″ (H150) | Details |
| Pushplate 200 | 4.5″ H × 4.5″ W | Double-gang electrical box | Full-plate square | Details |
Every model comes as ST (standard switch) or PNZ (pneumatic time delay), in blue, red or brushed aluminum. The H120 also comes in black or green.
Engraving
Choose PUSH TO EXIT, EXIT, PUSH TO OPEN, PUSH TO UNLOCK or OPEN (by model), leave the plate blank, or send us your own message or symbol. Custom engraving is free, done in-house on our own engraving machines.
Pushplate 120 / 140Most popular
Our most popular pushplate. A round button that can’t be burned or pried off, 1⅝″ or 2″.
Pushplate 100
Our classic exit release. Rectangular plate for a single-gang box.
Pushplate 110
The Pushplate 100 design, narrow enough for aluminum door frames.
Pushplate 130 / 150
Round-button exit release for narrow aluminum frames. 1⅝″ or 2″ button.
Pushplate 200
A large square plate for a double-gang box. Accessibility symbols available.
Not sure what your door needs?
Tell us about the opening. We'll put together the right kit, or build one to order.
